mesytec MPR-16-L provides a
state of the art multi channel charge integrating preamplifier, well
suited for silicon or gas detectors.
See also MPR-16-D type to drive differential lines.
See also MPR-16-D type to drive differential lines.
Features
- 16 channel compact module
- Very low power dissipation (4 V type)
- Sensitivity switch, factor 5
- ESD input protection
- Lemo output, can drive terminated BNC lines
- Pulser input
- Bias voltage up to ±400 V
- PCB module available for vacuum use
